Vibe Optisound Deltabox 6.2 Advanced OEM Integration LOC
R3 699,00
The VIBE OptiSound Delta Box 6.2 is a 6-channel line output converter designed for integrating aftermarket audio equipment with more complex factory sound systems while retaining the original head unit.
The DELTABOX6.2-V6 accepts up to six amplified speaker-level input channels and converts them into clean preamp-level outputs for connection to aftermarket processors, amplifiers and subwoofers.
Built-in signal summing allows multiple factory channels to be combined to reconstruct a full-range signal from multi-way OEM systems. Two dedicated subwoofer outputs provide additional flexibility for low-frequency system integration.
VIBE Bass Restoration technology helps recover bass reduced by factory processing as the volume increases, while selectable 20Ω, 60Ω and 20kΩ load options, 10–20V / 20–40V input ranges, multiple Auto Sense modes and Ground Lift settings allow the unit to be configured around a wide range of factory audio systems.
6.2 Advanced OEM Integration line output converter with 6-channel input + signal summing for complex factory systems. Combines multiple frequency-limited OEM channels into a usable full-range signal.
Features 4-channel output + dedicated subwoofer outputs, up to 40V OEM input handling (selectable 10-20V / 20-40V), OEM load simulation (20 Ohm / 60 Ohm / 20k Ohm), bass restoration, selectable 5V / 7.5V / 10V output plus independent channel level control, remote/DC offset/signal-sense turn-on, LPF/subsonic control, remote sub level & clip light.
High – Level Input Compatibility: 2-channel (2.1) or 6-channel (6.2) high-level input options allow seamless integration with even the most complex OEM systems, preserving factory head units while unlocking aftermarket potential.
Independent Output Level Control: Each channel features its own dedicated potentiometer, giving you precise control over output levels for fine-tuning your system balance and gain staging.
Bass Restoration Technology: Bring back the low-end your factory system hides! Independent bass restoration level and threshold controls (on subwoofer channels) let you recover deep bass that OEM systems filter out — so your music feels complete.
